Designed for High-Speed Water Filling Lines
KENI created this mineral water bottle capping machine for fast filling lines. We started making capping machines in 2015. Our factory has over 60 workers. We use advanced machines for processing. Our products go to the Middle East, South America, and Europe. This machine works perfectly with our Φ28mm bottle cap mold. The speed of your water line decides your profit. This capping machine helps you run faster and earn more.
Match Your Filling Line Speed with the Right Head Count
This mineral water bottle capping machine has 6 to 12 capping heads. The high-speed model has 12 heads. It produces 80 to 150 bottles per minute. That is 4,800 to 9,000 bottles per hour. It works with cap diameters from Φ28mm to Φ38mm. The standard water cap is Φ28mm. It fits bottle heights from 150mm to 320mm. This covers 500ml and 1L mineral water bottles. The capping torque is adjustable from 5N·m to 12N·m. The design prevents leaks. The power supply is 380V/3P/50Hz. The power rating is 3kW to 5.5kW. The machine body uses SUS304 stainless steel. This material is food grade and safe.
Technical Specifications
|
Parameter |
Specification |
|
Capping Heads |
6 – 12 heads (high-speed: 12 heads) |
|
Output |
80 – 150 bottles/min (4,800 – 9,000 bottles/hour) |
|
Cap Diameter |
Φ28 – 38mm (standard water cap: Φ28mm) |
|
Bottle Height Range |
150 – 320mm (for 500ml / 1L bottles) |
|
Capping Torque |
5 – 12N·m (adjustable, leak-proof design) |
|
Power Supply |
380V/3P/50Hz |
|
Power Rating |
3 – 5.5kW |
|
Machine Body Material |
SUS304 stainless steel (food grade) |
KENI does a 100% full inspection on every mineral water bottle capping machine. The capping pass rate is 99.5% or higher. We accept third-party quality checks. Our sales team will recommend the right head count based on your filling line speed. We have a dedicated service team. They respond fast to any problems. We pack each machine in a custom wooden case. We ship from Ningbo or Shanghai. We take payment in USD or RMB. We give a one-year free warranty. We offer lifetime maintenance. Repeat customers save 7 to 10 days on delivery. This machine is perfect for mineral water, purified water, and spring water filling lines.
