Versatile Capping for Beverage, Daily Chemical, and Medicine
KENI brings over 15 years of experience in mold and equipment manufacturing. Our R&D team has 10 engineers. We hold ISO quality management certification. Different industries need different caps. Beverage caps are not the same as daily chemical caps. Medicine caps have their own requirements. But all of them need a stable and fast capping machine. This high speed cap pressing machine meets all these needs with its wide range of applications.
Flexible Configuration for Various Cap and Bottle Types
This high speed cap pressing machine produces 100 to 200 bottles per minute. That is 6,000 to 12,000 bottles per hour. It handles cap sizes from Φ15mm to Φ50mm. This covers beverage caps, daily chemical caps, and medicine caps. The machine has 8 to 16 rotary capping heads. The torque control is digital and adjustable from 4N·m to 15N·m. It works with PET, PE, and PP plastic bottles. The bottle neck diameter range is Φ20mm to 60mm. The power rating is 4kW to 7.5kW. It uses 380V three-phase power. The machine dimensions are 3500×1200×1800mm. The weight is 800kg to 1200kg.
Technical Specifications
|
Parameter |
Specification |
|
Output |
100 – 200 bottles/min (6,000 – 12,000 bottles/hour) |
|
Cap Size |
Φ15 – 50mm (beverage / daily chemical / medicine caps) |
|
Capping Heads |
8 – 16 heads (rotary type) |
|
Torque Control |
4 – 15N·m (digital display, adjustable) |
|
Applicable Bottles |
PET / PE / PP plastic bottles, neck Φ20 – 60mm |
|
Power |
4 – 7.5kW, 380V three-phase |
|
Dimensions |
3500 × 1200 × 1800mm |
|
Weight |
800 – 1200kg |
KENI supports custom capping head designs based on your bottle shape. We offer discounts for large orders. Our sales team will study your cap specifications and bottle features. They will recommend the best capping head configuration. We share progress photos or videos during production. We do a 100% full inspection on every machine. The capping pass rate is 99.8% or higher. We accept third-party inspections. We provide a one-year free warranty. We offer lifetime quality service with a fee after one year. We do regular follow-ups to improve our service. This high speed cap pressing machine works well for beverage bottles, daily chemical bottles, medicine bottles, and seasoning bottles.
