Large Diameter and Heavy Weight for Oil Bottles
KENI operates from our factory in Huangyan, Taizhou. Our facility covers over 1,000 square meters. We use high-precision processing equipment. Our products sell well in the Middle East, South America, and Europe. Edible oil bottles are different from water bottles. They have larger neck openings. They use heavier preforms. They also hold more liquid per bottle. This edible oil PET preform mould is designed specifically for stable production of large oil packaging. We understand the unique needs of the edible oil industry.
Big Neck Sizes and Heavy Preform Weight
This edible oil PET preform mould uses mainstream neck diameters of Φ38mm, Φ45mm, or Φ50mm. The preform has 16, 24, or 32 cavities. We use fewer cavities for larger diameters. The preform wall thickness ranges from 2.8mm to 3.8mm. The cycle time is 35 to 45 seconds per mold. The sealing cap fitting tolerance is ±0.02mm. This ensures leak-proof performance. The thread pitch is 2.2mm to 2.5mm. The single preform weight is 35g to 65g. This fits injection molding machines with a tonnage of 300T to 450T. Our sales team will study your oil bottle capacity and sealing requirements. Our R&D team has 10 engineers. They can help you optimize the sealing structure design.
Technical Specifications
|
Parameter |
Specification |
|
Mainstream Neck Diameters |
Φ38 / Φ45 / Φ50mm |
|
Preform Cavities |
16 / 24 / 32 cavities (fewer for large diameters) |
|
Preform Wall Thickness |
2.8 – 3.8mm |
|
Cycle Time |
35 – 45s/mold |
|
Sealing Cap Tolerance |
±0.02mm |
|
Thread Pitch |
2.2 – 2.5mm |
|
Single Preform Weight |
35 – 65g |
|
Injection Molding Machine Tonnage |
300T – 450T |
KENI supports OEM and ODM services. We can produce based on your drawings or prototypes. We offer discounts for large orders. We do a 100% full inspection on every edible oil PET preform mould. The flash is 0.01mm or less. We accept third-party inspections. We share progress photos or videos during production. We provide a one-year free warranty. We offer lifetime quality service with a fee after one year. Repeat customers save 7 to 10 days on delivery time. This product is ideal for soybean oil bottles, peanut oil bottles, olive oil bottles, seasoning oil bottles, and other large-volume packaging.
