The Hinge Is the Heart of the Mold
The hardest part of a flip top cap is not the outside shape. It is the thin hinge. If the hinge is too thick, the cap will not open. If it is too thin, the hinge breaks. Taizhou KENI Mould Co., Ltd. has mastered this challenge. Our flip top cap mold controls hinge wall thickness precisely at 0.25 to 0.35mm. We test every design for over 50,000 open-close cycles. The hinge does not break. We use 8/16-cavity layouts. These fit diameters from Φ20 to 45mm. Cycle time is 12 to 18 seconds per shot. Flash at the hinge area stays at or below 0.01mm. This ensures smooth opening and closing with no sticking. Cavity hardness is HRC 50 to 54. This gives you long-term production stability.
Custom Solutions for Your Specific Cap
Our flip top cap mold shows our custom capability best. Before we start, we talk with you in detail. We ask about your hinge design, material grade, and expected service life. Then we give you a solid plan. During production, we follow strict process standards. If any issue comes up, we solve it quickly. After delivery, we provide operation training and maintenance guidance. This helps your line start production fast. Every flip top cap mold is inspected by our quality team. Hinge flash is controlled to our tight standard. We package in custom wooden cases for export. EXW and FOB terms are both available.
Technical Specifications
|
Parameter |
Specification |
|
Standard Cavities |
8 / 16 cavities |
|
Hinge Wall Thickness |
0.25 – 0.35mm |
|
Open-Close Cycles |
≥50,000 cycles |
|
Cycle Time |
12 – 18s per shot |
|
Compatible Diameter |
Φ20 – 45mm |
|
Hinge Flash |
≤0.01mm |
|
Cavity Hardness |
HRC 50 – 54 |
We have 60+ employees and a 1,000+ square meter workshop. Our equipment includes MAZAK and STUDER precision machines. We support custom orders based on your drawings or prototypes. Our quality team checks everything. We have a dedicated after-sales person for each customer. Repeat orders save 7 to 10 days of communication time. Our product serves shampoo caps, body wash caps, seasoning caps, and cosmetic caps. We understand the hinge is the most critical part. That is why we put extra care into every mold we make.
