Mirror‑Like Optical Surfaces for Accurate Readings
Blood coagulation cups require perfect optical surfaces. Surface roughness directly affects the reading accuracy of coagulation analyzers. Taizhou KENI Mould Co., Ltd. designed this Coagulation cup mould specifically for optical testing consumables. Standard cavities are 32 or 64. We offer three standard volumes: 0.5ml, 1ml, and 2ml. Cup wall thickness is 0.4 to 0.6mm. Optical surface roughness is Ra ≤0.02μm. That is a mirror finish. It ensures light transmission and test precision. Dimension tolerance is ±0.01mm. Cycle time is 9 to 13 seconds per shot. Each cavity has its own independent cooling circuit. This ensures even cooling and high part consistency. This Coagulation cup mould delivers reliable cups for critical diagnostic machines.
Every Optical Surface Is Tested
We inspect every Coagulation cup mould thoroughly. Optical surface roughness is checked cavity by cavity. Our 10‑person R&D team can help you optimize the optical surface design. We send you progress updates during production. We have a dedicated after‑sales team. They visit you and collect feedback. If shipping damage occurs, we fix it first. Then we find the root cause. We accept third‑party inspections. We offer a one‑year free warranty and lifetime maintenance. Repeat orders save 7 to 10 days. This Coagulation cup mould meets the highest demands for optical consumables.
Technical Specifications
|
Parameter |
Specification |
|
Standard Cavities |
32 / 64 cavities |
|
Standard Volumes |
0.5ml / 1ml / 2ml |
|
Cup Wall Thickness |
0.4 – 0.6mm |
|
Optical Surface Roughness |
Ra ≤0.02μm |
|
Dimension Tolerance |
±0.01mm |
|
Cycle Time |
9 – 13s per shot |
|
Independent Cooling per Cavity |
Yes |
Our factory uses CHARMILLES, HARDINGE, and DMG precision machines. We are ISO certified. We meet cleanroom standards for medical consumables. We support OEM and ODM orders. Packaging uses custom wooden cases. FOB Ningbo or Shanghai is available. Payment in USD or RMB. This Coagulation cup mould serves coagulation cups, cuvettes, reagent cups, and optical analysis consumables. We know that even a tiny scratch can change a test result. That is why we take optical quality very seriously.
