Specialized for Liquid Silicone Rubber
Silicone injection is different from plastic injection. The process is not the same. Taizhou KENI Mould Co., Ltd. designed this products specifically for LSR (liquid silicone rubber). It works for soft medical consumable production. Mold working temperature is 60 to 90℃. Curing time is 15 to 30 seconds per shot. That is longer than plastic cycles. But silicone offers unique material properties. Injection pressure is 80 to 120 bar. Minimum wall thickness can reach 0.3 to 0.5mm. This works well for thin‑wall soft silicone products. Dimension tolerance is ±0.01mm. Cavity material is 316L or S136 steel. Hardness is HRC 52 to 56. Surface roughness is Ra ≤0.05μm. This ensures easy demolding for silicone parts.
Deep Experience with LSR Cold Runners
Our 10‑person R&D team has deep experience with LSR molds. We understand cold runner design. We know temperature control matters. Before we build your products, we discuss your silicone material grade and hardness needs. We give you a solid plan. Every Medical silicone mold gets a 100% inspection. We accept third‑party inspections. We offer a one‑year free warranty and lifetime maintenance. If damage occurs during shipping, we fix it first. Our after‑sales team visits customers regularly. They collect feedback and make continuous improvements. Repeat orders save 7 to 10 days.
Technical Specifications
|
Parameter |
Specification |
|
Mold Working Temperature |
60 – 90℃ |
|
Curing Time |
15 – 30s per shot |
|
Injection Pressure |
80 – 120 bar |
|
Minimum Wall Thickness |
0.3 – 0.5mm |
|
Dimension Tolerance |
±0.01mm |
|
Cavity Material |
316L / S136, HRC 52 – 56 |
|
Surface Roughness |
Ra ≤0.05μm |
We have over 15 years of experience. Our factory uses high‑precision equipment. We are ISO certified. We meet medical‑grade production standards. Our quality team checks every Medical silicone mold before packing. Flash is kept at ≤0.01mm. Packaging uses custom wooden cases. FOB Ningbo or Shanghai is available. Payment can be in USD or RMB. This products serves many applications. These include silicone catheters, silicone masks, silicone seals, baby nipples, and medical soft consumables. We know that silicone molding requires special expertise. Our team has that expertise.
